Cooling Capacity (min-max) (kW) 3.52 (1.02-4.10) kW
Cooling Capacity (min-max) (Btu/h) 12,000 (3,480-14,000) Btu/h
EER (min-max) (Btu/hW) 13.16 (13.92-12.12) Btu/hW
EER (min-max) (W/W) 3.42 (3.71-3.25) W/W
CSPF (W/W) 5.41 W/W (5★)
Voltage (V) 220-240 V
Current (A) 4.8-4.4 A
Power Input (min-max) (W) 1,030 (275-1,260) W
Moisture Removal (L/h) 2.0 L/h
Moisture Removal (Pt/h) 4.2 Pt/h
Indoor Unit Air Circulation 11.0 m³/min (390 ft³/min)
Indoor Unit Noise Level (H / L / Q-Lo) 40/26/21 dB(A)
Indoor Unit Dimensions (H x W x D) (mm) 290 mm x 765 mm x 214 mm
Indoor Unit Dimensions (H x W x D) (inch) 11-7/16 inch x 30-1/8 inch x 8-7/16 inch
Indoor Unit Net Weight 8 kg (18 lb)
Indoor Unit Gross Weight 9 kg (20 lb)
Outdoor Unit Air Circulation 30.6 m³/min (1,080 ft³/min)
Outdoor Unit Noise Level (H) 48 dB(A)
Outdoor Unit Dimensions (H x W x D) (mm) 542 mm x 780 mm x 289 mm
Outdoor Unit Dimensions (H x W x D) (inch) 21-11/32 inch x 30-23/32 inch x 11-13/32 inch
Outdoor Unit Net Weight 22 kg (49 lb)
Outdoor Unit Gross Weight 25 kg (55 lb)
Refrigerant Type R32
Refrigerant Amount (g) 450 g
Refrigerant Pipe Diameter (Liquid Side) ø ø 6.35 mm (1/4 inch)
Refrigerant Pipe Diameter (Gas Side) ø 9.52 mm (3/8 inch)
Pipe Extension (Chargeless Pipe Length) 7.5 m
Pipe Extension (Maximum Pipe Length) 20 m
Pipe Extension (Maximum Elevation Length) 15 m
Pipe Extension (Additional Refrigerant Gas*) 10 g/m
Power Supply Indoor
nanoe™ X Yes (Generator Mark 2)
nanoe-G Yes
Inside Cleaning On Demand Yes
Odour Removing Function Yes Yes
Removable, Washable Panel Yes
Anti-Dust Cross Flow Fan Yes
Wi-Fi Built-in (Easy Connect)
24-Hour Dual ON & OFF Real Setting Timer Yes
LCD Wireless Remote Control Yes
Wired Remote Control Optional
Powerful Mode Yes
Sleep Mode Yes
Quiet Mode Yes
Soft Dry Operation Mode Yes
Personal Airflow Creation –
Airflow Direction Control (Up & Down) Yes
Manual Horizontal Airflow Direction Control Yes
Inverter Control Yes
ECO Mode with A.I. Yes
Random Auto Restart Yes (32 Restart Patterns)
Blue Fin Condenser Yes
Long Piping (maximum) 20 m
Top Panel Maintenance Access Yes
Self-Diagnostic Function Yes
Note *When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit.
Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.
*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit.
