4K LCD/HDR Bright Panel
Resolution (W x H)
4K Ultra HD/3,840 x 2,160
Multi HDR Support*²
HDR10+/HDR10/HLG decoded only
Adaptive Backlight Dimming
Dolby Vision IQ
4K Studio Colour Engine
HEXA Chroma Drive
Hexa Chroma Drive
Auto AI for Picture
20 W (10 W x 2)
Auto AI for Sound
Google Assistant*³ Built-in
Works with Google Assistant
Works with Alexa*⁴
Panasonic TV Remote 3 App (swipe & share)
Easy Mirroring/Chromecast built-in
AVI/MKV/MP4/TS/VOB/MPG/DAT, MP3/AAC, JPG/JPEG
HDMI 2.1 VRR Support
HDMI 2.1 HFR – 120Hz Support
AMD Freesync Premium*⁷
Wireless LAN Built-in*⁹
(BT5.0, 2 ways)
Bluetooth Audio Link*¹¹
HDMI Support Feature
eARC (Enhanced Audio Return Channel) (Input ? )
HDMI Signal Power Link
2 (side; USB 3.0 x 1, USB 2.0 x 1)
CI (Common Interface)
Analogue (Composite) Video Input
M3 x 1 (side)
Component Video Input shared with Composite
Digital Audio Output (Optical)
Digital Audio Output (Coax)
Analogue Audio Output
PC input (VGA) + PC Audio In
On Screen Display Menu Languages
English/Simplified Chinese +…(Follow Android system)
Visible Screen Size (diagonal)
189 cm / 75 inches
Standby Power Consumption
AC 220 – 240 V, 50/60 Hz
Rated Power Consumption
Ambient Sensor (CATS)
Dimensions (W x H x D) (w/o stand)
1,689 x 960 x 89 mm
Dimensions (W x H x D) (with stand)*¹⁵
1,689 x 1,031 x 353 mm
Weight (w/o stand)
Weight (with stand)
Dimension Pedestal (W x D)
1,464 x 353 mm
VESA Dimension (W x H)
400 x 300 mm
Outer Boxed Unit (W x H x D)
1,840 x 1,103 x 190 mm
Total Boxed Weight
*1 Features and specifications are subject to change without prior notification. Internet connection is required with smart functions.
*2 All models: Supporting HDR does not increase the peak brightness capabilities of the TV panel.
Full HD & HD models: The ability to send a non 4K HDR signal via HDMI depends fully on the playback device. The majority of 4K Blu-ray discs require HDCP2.2 on TV to play back HDR. Please check the HDCP version of HDMI inputs. Not all HDR contents are guaranteed to be enjoyed on the TV.
*3 Google, Android TV and Chromecast built-in a trademarks of Google LLC
Google Assistant is not available in certain languages and countries
Requires internet connection. Subscriptions for services may be required.
*4 Amazon, Alexa is not available in certain languages and countries. Requires internet connection. Subscriptions for services may be required.
*5 File formats that are not supported by your Network Contents server (DLNA compatible server, etc.) cannot be played.
*6 The Web Browser cannot display some web pages correctly. And viewable contents by the Web Browser are subject to the following conditions;
– viewable contents may vary depend on models,
– viewable contents may differ from those for PC,
– viewable contents may be limited.
*7 ©2020 Advanced Micro Devices, Inc. All rights reserved. AMD and FreeSync and combinations thereof are trademarks of Advanced Micro Devices, Inc.
*8 ©2021 NVIDIA, the NVIDIA logo, and NVIDIA G-SYNC are
trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries.
*9 In case the password of the registered device or user is known by a third party, there is a risk of unauthorized entries. Keep your password safe. Panasonic will make no warranty for the unauthorised entries.
To prevent a risk of interception, unauthorised entries and hacking, set up the proper security settings (encryption setting).
*10 HID (Human Interface Device Profile) compliant keyboards are available. A2DP (Advanced Audio Distribution Profile) compliant audio devices are available. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license.
*11 When a Bluetooth device is connected to the TV, it is possible that the Bluetooth audio output may not be synchronized (i.e. be delayed) with relation to the images on the screen. This is not a defect of the TV or the device. The delay time will differ depending on the device.
*12 The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
*13 This feature requires a USB hard drive or flash drive with a capacity of at least 160 GB.
*14 Not all the accessories are listed here.
*15 Dimension with recommended pedestal style.
*16 Supporting HSP standardized by CTA-2072 (HDR Still Photo Interface)
*17 To playback HDR, a HDR source is required (H.264 or H.265(ST2084 or HLG format)).
*18 10 Languages [English/Chinese(Simplified)/Arabic/Persian/French/Thai/Vietnamese/Indonesia/Hindi/Burmese]Panasonic 75″ TH-75MX650K 4K HDR Google LED TV
